Vogue 5.7 LA (TL)
Architectural Trimless Linear wall grazer with dark light louvre
Product Overview
✔ Individual LED spotlights concealed within a darklight louvre, ideal for wall washing
✔ Available in single lengths of upto 3m and connected together to form long, straight runs
✔ Pitch of LEDs: 50mm
✔ Choice of beam angles available
✔ Standard, DALI or Casambi drivers, integral from to the luminaire
✔ Contact sales for help with pattern forming this product
✔ Suitable for Hospitality, Office, Retail, Gallery/Museum, Leisure
Finishes / Material
-
Black (Matt) RAL 9005 -
White (Signal) RAL 9003
-
Body: Extruded Aluminium
-
Louvre: Aluminium
Sizes
-
406 (L) mm x 53 (W) mm x 70 (H) mm x Incl. Bracket 90 (D) mm mm
-
606 (L) mm x 53 (W) mm x 80 (H) mm mm
-
906 (L) mm x 53 (W) mm x 80 (H) mm mm
-
1206 (L) mm x 53 (W) mm x 80 (H) mm mm
-
1506 (L) mm x 53 (W) mm x 80 (H) mm mm
-
1806 (L) mm x 53 (W) mm x 80 (H) mm mm
-
2406 (L) mm x 53 (W) mm x 80 (H) mm mm
-
3006 (L) mm x 53 (W) mm x 80 (H) mm mm
-
>3006 (L) mm mmFor longer lengths please contact sales
-
M2M (L) mm mmMade to measure length
*Please Note: Made to measure sizes available - contact sales
- Source Info Tier 1 LED components (Tridonic, Philips, Osram)
- Lumens (delivered) 889Lm - 12351Lm
- Circuit Watts 11cW - 132cW
- Efficacy up to 101Lm/cW
- MacAdams Cree 2 SDCM
- Colour Temperature 3000K (2SDCM Single Bin)
- Colour Rendering CRI90
Options.
Beam Angle
-
17° Beam Angle
-
36° Beam Angle
Louvre Finish
-
Black
-
White
-
Gold
Mount (optional)
-
Suspension wire kit (1.2m)
-
Suspension wire kit (3m)
Additional Information.
Vogue 5.8 LA is an architectural surface mounted linear wall grazer. Available in matt black, anodized silver or white, this high performance linear wall washer is ideal for providing uniform accent lighting to wall surfaces. If you are looking for a linear wall light to emphasise textured wallpapers or feature walls then Vogue 5.8 LA is a great choice.
